主要用途与简价/Brief Introduction：

全智能齿轮泵式膏体酱灌装生产线设备机是爱总部改变销售市场供需開發的新產品。此机采用了SUS304装饰管齿轮泵式计算泵执行力灌装生产线设备，且集智能上盖、智能旋盖、汽车电器电气开关为整体，国家经济实惠，占室内地绿地面积绿地面积小，范围广适用于医药、食品原料、除草剂、石油化工、化妆造型品等行业领域的固态彩盒，不符合GMP管理规范必须。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

结构特征/characteristic：

◆进行轴向柱塞泵式剂量泵执行工作分装，不适用各种各样的黏稠度介质液体，高精准度大；泵的设备构造进行快接式拆装工作贷款机构，能够除垢、清洁。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式的计量泵活塞环环的材料可根据制造行业及药液基本成分的与众不同所采用了硅聚氨酯材料，四氟丁二烯或任何的材料，特色的场所所采用了陶瓷制品的材料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC状况软件，变频式变速，自己化情况高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，自行数值功能性。Lack of bottle filling, automatic counting function◆装量修改方便快捷，可是一次修改另一个计算泵的充填量，也可争对各种计算泵开始微幅修改；操作步骤简单，修改迅速的。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆灌装线生产线针头开设防渗漏仪器，充填时潜进瓶底灌装线生产线，缓缓增长，杜绝小气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆组装机可适于各种金桥铜业跨接线的截面积大小的罐子，调准非常简单，可在短期间内来完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆机床按GMP规范要求装修设计。The machine designed according to the requirements of GMP

新技术指标/technic parameter：

使用小瓶产品规格Size of bottles	20-1000ml（可根据规定要求订制）20-1000 - ml (according to your need）
适用人群塑料瓶直徑Apply the bottle diameter	¢20-¢150mm
支持盖子规格参数Apply the lid specifications	¢20-¢70mm
生产方式力 production capacity	四头分装：1000-2500瓶/钟头 Four filling head: 1000-2500 bottles per hour 八头罐装：2500-4000瓶/小时候 Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/几小时 12 head filling: 4000-6000 bottles per hour
装量误差度The load error	±1%
旋盖达标率率Screw cover percent of pass	≥99%
电原power supply	380V，50HZ
输出功率power	3.0KW
汽源gas sources	0.4-0.75MPA
访问速度管控speed control	变頻变速variable speed
