适用范围与介绍/Brief Introduction：

什么是服务器利用唯一性三通接头罐装生产专用设备阀，适于于水剂和膏霜类企业产品的罐装生产专用设备，特点对高粘稠度物料管理管理（如浓酱、青椒酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的目的对比比较明显，且精准度不高。什么是服务器利用PLC可java开发保持，配合6寸大触屏屏人与机器画面生产专用设备，进行 定时进瓶，定时罐装生产专用设备，定时出瓶，电气产品，气动平衡元部分均利用香港国际茶叶品牌，确认了漂亮的安全效能和持久性平衡的效能。本生产专用设备节构非常简单，实际操作方便快捷，是中国大陆理想型的争对高粘稠度物料管理管理的罐装生产专用设备生产专用设备。什么是服务器增配了阻止漏滴与金属不锈钢拉丝的罐装生产专用设备闷头，确认罐装生产专用设备已完成后无漏滴，无金属不锈钢拉丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

的特点/Characteristic：

◆调控整体——用到三菱PLCPLC调控整体，灌装线用药量随时稍微调一下。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆操作使用流程表面——6屏幕尺寸彩屏手触式操作使用流程表面，更直观单纯、很安全靠得住Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆效果改善——上下料有防渗漏控制系统，可表明货位性能表拥有下潜罐装效果。（此效果不错所采用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电嚣构件——均通过香港国际有名气产品品牌，抓实主设备的安全保障稳定可靠、为准高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆厂家核心部件——服务器核心部件均用于好的304不锈碳钢作,如果有必须使用材料也可以用于316L另收取用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆计数器器检查测量——城市热力图计数器器，对的工作时产直观性投诉。Counting test, real-time, intuitive reflect the yield of work.◆罐装加测——无瓶不灌、瓶数不高不灌Bottle filling test - no bottle no filling, not enough◆维修事情——远程服务器合乎GMP追求，可容易拆解、除污维修。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆的调整金桥铜业跨接线的截面积大小参数——换掉装灌金桥铜业跨接线的截面积大小参数时，只需要简单化的调整，轻松愉快拿下。Changing specifications - change the filling specifications, simply adjust, easy fix.◆节能配备——配备了节能结构框架，使机子的作业氛围更进一步的清洁健康。（此节能配备能否加配）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术设备规格/technical parameters：

罐装头数The number of filling head	8头（必选4、6、൲8、10、14个罐装头）8 head🔯 (optional 4, 6, 8, 10, 12 filling head)
应用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计算精确度measure precision	±1%
罐装容积Canned capacity	150-1000ml
产生作用Production Capacity	2400-4000瓶/个小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
